1×40 Ft Cliffside Studio Container Home | Full Glass Front

$12,000.00

Shop our 1×40 ft Cliffside Studio Container Home with full glass front panel. Cor-Ten steel frame, off-grid ready, architectural modular design. Free shipping available. Order now.

The 1×40 Ft Cliffside Studio Container Home redefines modular living with a striking architectural profile built for dramatic settings — cliffside, coastal, forest-edge, or high-desert. At its core is a full-width floor-to-ceiling glass front panel that floods the interior with natural light and connects the occupant to the surrounding landscape in an unobstructed, panoramic sweep.

Fabricated from a high-grade Cor-Ten weathering steel ISO shipping container, this unit is engineered to endure. The exterior weathers naturally to a rich, oxidized patina that requires zero maintenance, while the thermally broken structural frame ensures energy performance in climates ranging from alpine cold to coastal humidity.

The interior shell arrives factory-finished with spray foam insulation, vapor barrier, and a structural sub-floor ready for your finish flooring. The glass front unit integrates a commercial-grade frameless sliding door system with double-pane, low-E tempered glass panels, thermally isolated from the steel frame to eliminate cold bridging. Steel connection plates and ISO corner castings on all eight corners allow single-unit standalone placement or multi-unit stacking and side-by-side assembly.

Designed for off-grid, grid-tied, or hybrid energy setups, the unit ships with pre-cut conduit chases, a breaker-panel rough-in box, and plumbing stub locations pre-marked on the floor and sidewall. Structural cutouts for mini-split HVAC, ventilation, and exterior utility connections are factory-fabricated and capped for shipping. Every unit undergoes full pressure-wash, interior blast, epoxy prime, and two-coat finish before dispatch.

Whether deployed as a primary residence, a remote studio, a premium guest house, or a short-term rental asset, the Cliffside Studio delivers industrial material quality with architectural spatial intent — a rare combination at this price point in the modular dwelling market.


Full Spec Sheet
Unit Configuration
1×40 Ft ISO Standard Container
Exterior Dimensions (L×W×H)
12.19 m × 2.44 m × 2.89 m (40′ × 8′ × 9′6″ HC)
Interior Dimensions (L×W×H)
11.99 m × 2.28 m × 2.69 m
Interior Floor Area
27.3 m² (294 sq ft)
Container Grade
One-Trip / New Build, ISO 1C Certified
Frame Material
Cor-Ten A606 Weathering Steel
Tare Weight (Unmodified)
3,800 kg (8,380 lbs)
Max Gross Weight
30,480 kg (67,200 lbs)
Glass Front System
Full-Width Floor-to-Ceiling (8.5 m span)
Glass Spec
Double-Pane, Low-E Tempered, 8 mm + 16 mm air gap + 8 mm
Glass U-Value
1.1 W/m²K
Glass SHGC
0.27 (low solar heat gain)
Door System
Frameless Aluminum Sliding + Fixed Lites
Door Opening Width
1.8 m clear (double-panel slide)
Wall Insulation
Closed-Cell Spray Foam, 75 mm, R-30
Ceiling Insulation
Closed-Cell Spray Foam, 100 mm, R-40
Floor Insulation
50 mm Rigid EPS Board, R-20
Exterior Finish
Natural Cor-Ten Weathering Patina (bare) or 2-coat Enamel
Interior Wall Finish
Spray-Applied Epoxy Primer, Ready for Ply/Drywall
Sub-Floor
19 mm Marine-Grade Plywood on Steel Cross Members
Corner Castings
8× ISO Standard Forged Steel (stackable, lashable)
Stack Rating
Up to 9 High (loaded), 3 High (finished unit)
Electrical Rough-In
200A Main Breaker Panel Stub, PVC Conduit Chases
Plumbing Stub-Ins
2× ¾″ Supply, 1× 3″ Drain (floor penetrations)
HVAC Cutout
Pre-Cut for 12,000–18,000 BTU Mini-Split Head Unit
Ventilation Port
2× Capped 150 mm Penetrations (rear wall)
Wind Rating
220 km/h (Category 4 Hurricane Equivalent)
Seismic Rating
Zone 4 Compliant (with engineered foundation)
Snow Load Capacity
180 kg/m² (with structural lid reinforcement option)
Delivery Mode
Flat-bed Semi or Crane-off; Site Access Min. 3.5 m Clearance
Lead Time
1–2 Weeks
Warranty
5-Year Structural / 2-Year Glass Seal / 1-Year Finishes
